모형: GSKJ-PET
| 다운로드 | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
| Specification sheet | |||||
| Part No. | Nominal size - W | Expandable range | Packing -L | ||
| Inch | mm | Min.I (mm)Caption | Max.O (mm) | standard spool | |
| GSKJ-PET-003 | 1/8″ | 3 | 1 | 6 | 100M/R |
| GSKJ-PET-005 | 1/4″ | 6 | 3 | 9 | 100M/R |
| GSKJ-PET-008 | 5/16″ | 8 | 5 | 16 | 100M/R |
| GSKJ-PET-010 | 3/8″ | 10 | 7 | 19 | 100M/R |
| GSKJ-PET-012 | 1/2″ | 12 | 8 | 24 | 100M/R |
| GSKJ-PET-016 | 5/8″ | 15 | 10 | 27 | 100M/R |
| GSKJ-PET-019 | 3/4″ | 20 | 14 | 30 | 50/R |
| GSKJ-PET-025 | 1″ | 25 | 18 | 35 | 50M/R |
| GSKJ-PET-032 | 1 -1/4″ | 30 | 20 | 50 | 50M/R |
| GSKJ-PET-038 | 1 -1/2″ | 40 | 30 | 60 | 25M/R |
| GSKJ-PET-045 | 1 -3/4″ | 45 | 35 | 75 | 25M/R |
| GSKJ-PET-050 | 2″ | 50 | 40 | 80 | 25M/R |
| GSKJ-PET-064 | 2 -1/2″ | 64 | 45 | 105 | 25M/R |
