모형: GSKJ-PAW
The file is encrypted. Please fill in the following information to continue accessing it
| Specification sheet | |||||
| Part No. | Nominal size - W | Expandable range | Packing -L | ||
| Inch | mm | Min.I (mm) | Max.O (mm) | standard spool | |
| GSKJ-APW-003 | 1/8″ | 3 | 1 | ≥3 | 100M/R |
| GSKJ-APW-005 | 1/4″ | 6 | 3 | ≥5 | 100M/R |
| GSKJ-APW-008 | 5/16″ | 8 | 5 | ≥6 | 100M/R |
| GSKJ-APW-010 | 3/8″ | 10 | 7 | ≥7 | 100M/R |
| GSKJ-APW-012 | 1/2″ | 12 | 8 | ≥9 | 100M/R |
| GSKJ-APW-016 | 5/8″ | 15 | 10 | ≥11 | 100M/R |
| GSKJ-APW-019 | 3/4″ | 20 | 14 | ≥14 | 50/R |
| GSKJ-APW-025 | 1″ | 25 | 18 | ≥17 | 50M/R |
| GSKJ-APW-032 | 1 -1/4″ | 30 | 20 | ≥18 | 50M/R |
| GSKJ-APW-038 | 1 -1/2″ | 40 | 30 | ≥22 | 25M/R |
| GSKJ-APW-045 | 1 -3/4″ | 45 | 35 | ≥26 | 25M/R |
| GSKJ-APW-050 | 2″ | 50 | 40 | ≥35 | 25M/R |
| GSKJ-APW-063 | 2 -1/2″ | 63 | 45 | ≥43 | 25M/R |
