모형: GSKJ-KLB-1
The file is encrypted. Please fill in the following information to continue accessing it
| Specification sheet | |||||
| Part No. | Nominal size - W | Expandable range | Packing -L | ||
| Inch | mm | Min.I (mm) | Max.O (mm) | standard spool | |
| GSKJ-KLB-003 | 1/8″ | 3 | 2 | ≥3 | 100M/R |
| GSKJ-KLB-006 | 1/4″ | 6 | 4 | ≥5 | 100M/R |
| GSKJ-KLB-008 | 5/16″ | 8 | 5 | ≥6 | 100M/R |
| GSKJ-KLB-010 | 3/8″ | 10 | 6 | ≥7 | 100M/R |
| GSKJ-KLB-012 | 1/2″ | 12 | 8 | ≥9 | 100M/R |
| GSKJ-KLB-016 | 5/8″ | 15 | 10 | ≥11 | 100M/R |
| GSKJ-KLB-019 | 3/4″ | 20 | 12 | ≥14 | 50/R |
| GSKJ-KLB-023 | 1″ | 25 | 15 | ≥17 | 50M/R |
| GSKJ-KLB-025 | 1 -1/4″ | 30 | 16 | ≥18 | 50M/R |
| GSKJ-KLB-032 | 1 -1/2″ | 40 | 20 | ≥22 | 25M/R |
| GSKJ-KLB-038 | 1 -3/4″ | 45 | 24 | ≥26 | 25M/R |
| GSKJ-KLB-050 | 2″ | 50 | 32 | ≥35 | 25M/R |
| GSKJ-KLB-063 | 2 -1/2″ | 64 | 40 | ≥43 | 25M/R |
