모형: GSKJ-BWG-1
The file is encrypted. Please fill in the following information to continue accessing it
| Specification Sheet | |||||
| Part No. | Internal diameter (mm) |
Outer Diameter（mm） | Bending Radius (mm) |
Packing (m/r) |
Remark |
| AD7 | 5±0.5 | 7±0.5 | 15 | 500 | |
| AD7.5 | 5.5±0.5 | 7.5±0.5 | 15 | 500 | |
| AD9.0 | 6±0.5 | 9±0.5 | 15 | 500 | |
| AD10.0 | 7±0.5 | 10±0.5 | 25 | 500 | Standard Size |
| AD11.0 | 8±0.5 | 11±0.5 | 25 | 500 | |
| AD12.0 | 9±0.5 | 12±0.5 | 25 | 500 | |
| AD13.0 | 10±0.5 | 13±0.5 | 30 | 500 | Standard Size |
| AD14.0 | 11±0.5 | 14±0.5 | 30 | 200 | |
| AD15.8 | 12±0.5 | 15.8±0.5 | 35 | 200 | Standard Size |
| AD17.0 | 13±0.5 | 17±0.5 | 35 | 200 | |
| AD18.5 | 14.5±0.5 | 18.5±0.5 | 40 | 200 | Standard Size |
| AD19.0 | 15±0.5 | 19±0.5 | 45 | 200 | |
| AD20.0 | 16±0.5 | 20±0.5 | 50 | 200 | |
| AD21.2 | 17±0.5 | 21.2±0.5 | 50 | 200 | Standard Size |
| AD22.0 | 18±0.5 | 22±0.5 | 50 | 100 | |
